CHANNEL 300x2000 CENTER OUTLET - (670EK020-10BA)

Part Of the Series: Channel-No membrane

Type no.: 670EK020-10BA

EAN no.: 5705499129830

Size: 300x2000

Product Specification
Field of Application Industrial
Floor Concrete / Tiled / Resin
Material AISI 304
Material (EN) EN 1.4301
Membrane Type No Membrane
Minimum Height (mm) 170
Outlet Box No
Outlet dia. (Inch) 6
Outlet Diameter (mm) 160
Outlet Direction Vertical
Outlet Placement Center
Shape Rectangular
Size (Inch) 11¾x78¾
Size (mm) 300x2000
Weight (kg) 17,00
Weight (lbs) 37,48
