SHOWER CHANNEL WATERLINE 1000 - (178.100.056.20)
Part Of the Series: Shower channel-No membrane
Type no.: 178.100.056.20
EAN no.: 5705499138139
VVS no.: 155061010
NRF no.: 3394811
Size: 50x1000
SHOWER CHANNEL WATERLINE 1000
-Floor: concrete and tiled
-No membrane, frame: rectangular
-Outlet: Ø50mm, vertical
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Field of Application | Domestic |
Floor | Concrete / Tiled |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Membrane Type | No Membrane |
Outlet Box | No |
Outlet dia. (Inch) | 2 |
Outlet Diameter (mm) | 50 |
Outlet Direction | Vertical |
Outlet Placement | End |
Shape | Rectangular |
Size (Inch) | 2x39⅜ |
Size (mm) | 50x1000 |
Weight (kg) | 1,78 |
Weight (lbs) | 3,92 |
-
Downloads
-
Approvals and standards
For approvals and standards information, please refer to the below certificates.
