SWEPT BRANCH 87.5° - (839.050.075 S)
×
![]()
Part Of the Series: Swept branch-87.5-long bend
Type no.: 839.050.075 S
EAN no.: 5705499402544
VVS no.: 160222373
RSK no.: 1550383
NRF no.: 2170787
LVI no.: 0255235
SWEPT BRANCH 87.5°
-Pipe diameter: Ø75mm. Branch diameter: Ø50mm
-Stainless steel: AISI316L/EN1.4404
| Product Specification | |
|---|---|
| Angle (°) | 87.5 |
| Length (mm) | 144 |
| Material | AISI 316L |
| Material (EN) | EN 1.4404 |
| Outlet dia. (Inch) | 3 |
| Outlet Diameter (mm) | 75 |
| Weight (kg) | 0,60 |
| Weight (lbs) | 1,32 |
-
Downloads
-
Approvals and standards
For approvals and standards information, please refer to the below certificates.
US - IAPMO File No.3247-EuroPipe
HACCP Food Safety Programme - Europe
DK - VA 2.12/19349 EuroPipe DS432 Lloyds Register LR22419510TA_02 DNV - TAP0000023-rev5, Sanitary discharge pipes PL - Hygienic Certificate - All Products MARINE - R4547 NATO CODIFICATION SYSTEM Bureau Veritas, 02375-I0 Pipes & Fittings ABS - 23-2329630-PDA UR - 1055745 Product approval, EuroPipe and Drains RINA -MAC285119XG EuroPipe Achilles Certificate - 46702-22 KR - Type Approval CPH42135-PE001
