MOUNTING SET LINE TOKYO 1200 - (650.350.120)
Part Of the Series: MULTI top-Channel
Type no.: 650.350.120
EAN no.: 5705499135435
RSK no.: 7129527
NRF no.: 3394351
LVI no.: 3304189
Size: 130x1200
MOUNTING SET LINE TOKYO 1200
-With clamping ring
-Floor: concrete and tiled
-Frame: rectangular
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Field of Application | Domestic |
Floor | Concrete / Tiled |
Load Class EN1253 | K3 |
Load Class EN1253 (kg) | K3 (300) |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Minimum Height (mm) | 41 |
Outlet dia. (Inch) | 4 |
Outlet Diameter (mm) | 112 |
Shape | Rectangular |
Size (Inch) | 5⅛x47¼ |
Size (mm) | 130x1200 |
Weight (kg) | 6,15 |
Weight (lbs) | 13,56 |
-
Downloads
-
Approvals and standards
For approvals and standards information, please refer to the below certificates.
